Product Description:
A parallel twin-screw barrel is an essential element in the operation of twin-screw extruder systems. It comprises two screws that rotate side by side within a barrel. These barrels are strategically structured to complement the screws, aiding in a variety of material processing activities.
The screws may rotate in a co-rotating or counter-rotating manner, with co-rotating configurations being more prevalent in applications such as plastic compounding and extrusion. The barrel itself is often segmented, allowing for convenient replacement and customization to cater to specific processing needs.
Screw diameters can vary significantly, ranging from as diminutive as 12 mm for small-scale extruders used in laboratories to over 350 mm for large-scale industrial applications.
Applications:
Plastic Compounding: Parallel twin screw barrels are widely used for compounding different types of plastics. This includes blending polymers with additives like antioxidants, UV stabilizers, and flame retardants to enhance the properties of the final plastic product. They are also used for creating polymer alloys, such as blending polycarbonate (PC) with acrylonitrile - butadiene - styrene (ABS) to combine the best properties of both materials.
Masterbatch Production: As mentioned earlier, they play a crucial role in manufacturing masterbatches. By precisely mixing a small amount of highly concentrated colorants or additives with a base polymer, masterbatches are produced, which are then used to color or modify the properties of larger volumes of plastic during the final manufacturing process.
Plastic Recycling: In plastic recycling facilities, parallel twin screw extruders with suitable barrel designs are used to process recycled plastics. The extruder can melt, clean, and compound the recycled plastic materials, removing impurities and re-compounding them into usable plastic pellets for further manufacturing.
Customization:
Product Customization Services for ALVEN PARALLEL TWIN Screw Barrel:
Brand Name: ALVEN
Model Number: PARALLEL TWIN
Place of Origin: ZHEJIANG ZHOUSHAN
Minimum Order Quantity: 1 SET
Price: 1200-3000 USD/Set
Packaging Details: Standard wooden box
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 100 SETS PER MONTH
Nitride Brittleness: ≤Level 1
Nitride Depth: 0.5-0.8mm
Nitriding Depth: 0.5-0.8mm
Heating Method: Ceramic Heater, Cast Aluminum Heater
Nitriding Hardness: ≥950HV
Packing and Shipping:
Product Packaging for Parallel Twin Screw Barrel:
The Parallel Twin Screw Barrel will be carefully packaged in a sturdy cardboard box with protective foam padding to prevent any damage during transit.
Shipping Information:
We offer worldwide shipping for the Parallel Twin Screw Barrel. The product will be shipped via a reliable courier service with tracking information provided to ensure safe and timely delivery.
FAQ:
Q: What is the brand name of this twin screw barrel?
A: The brand name is ALVEN.
Q: What is the model number of this twin screw barrel?
A: The model number is PARALLEL TWIN.
Q: Where is this twin screw barrel manufactured?
A: The product is manufactured in ZHEJIANG ZHOUSHAN.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity is 1 SET.
Q: What are the accepted payment terms for purchasing this twin screw barrel?
A: The accepted payment terms are L/C and T/T.
