Industrial Grade Extruder Screw Barrel With Bimetallic Treatment HRC58-62 Hardness 3-5 Heating Zones

Product Description:

Screw barrels are crucial components of extruders, playing a key role in the melting, conveying, and extrusion efficiency of materials. Depending on the presence of venting structures, they are categorized into vented screw barrels and non-vented screw barrels. Each type is designed to cater to specific processing requirements, making them suitable for various materials and production scenarios.

Vented screw barrels are specifically engineered with one or more vent holes (typically 1-2) on the barrel, along with a corresponding vent section on the screw. This configuration is intended for the removal of volatile substances (such as moisture, air, solvents, or gases) from materials during the extrusion process, ensuring the purity and stability of the end product.

Non-vented screw barrels, on the other hand, are the standard type that lacks vent holes or vacuum structures. They are focused on efficient material conveying, melting, and extrusion, making them suitable for materials with low gas content or stable properties that do not require degassing.

Applications:

Designed to cater to a specific set of material requirements, our material drying equipment is most suitable for substances that are prone to trapping gases or contain volatile components. This includes:

• Recycled plastics, which may absorb moisture or contain residual solvents.
• Hygroscopic materials like PA (polyamide) and PC (polycarbonate).
• Materials requiring high purity, such as medical-grade plastics or food packaging materials.

On the other hand, our equipment is also highly effective for dry, low-volatile, or high-stability materials, which include:

• Common non-hygroscopic plastics like PP (polypropylene) and PE (polyethylene).
• Pre-dried materials that have been fully dehumidified.
• Materials for simple extrusion processes such as film blowing, pipe extrusion, or profile extrusion, where minor gas content has little impact on product performance.

Customization:

Product Customization Services for the ALVEN Vent Screw Barrel:

- Brand Name: ALVEN

- Model Number: Vent Screw Barrel

- Place Of Origin: Zhoushan China

- Nitriding hardness: HV900-1000

- Base Materials: 38CrMoAlA

- Surface treatment: Nitriding / Bimetallic Treatment

- Nitride Depth: 0.5~0.8mm

- Surface Roughness: Ra0.4

Customize your screw barrel for plastic recycling with ALVEN Vent Screw Barrel. Our product is designed for recycling plastic extruder, making it an ideal choice for extruder machine parts.

Support and Services:

Our product technical support and services for the Extruder screw barrel include:

- Expert assistance with installation and setup

- Troubleshooting guidance for any operational issues

- Regular maintenance tips to prolong the lifespan of the screw barrel

- Upgrades and customization options for specific requirements

Packing and Shipping:

Product Packaging:

The Extruder screw barrel will be securely wrapped in bubble wrap to prevent any damage during transit. It will then be placed in a sturdy cardboard box with appropriate cushioning materials to further protect it from any impacts.

Shipping:

We offer reliable shipping services to ensure that your Extruder screw barrel reaches you safely and on time. The product will be shipped using a reputable courier service with tracking information provided to you so you can monitor the delivery status.

FAQ:

Q: What is the brand name of this screw barrel product?

A: The brand name is ALVEN.

Q: What is the model number of this screw barrel product?

A: The model number is Vent Screw Barrel.

Q: Where is this screw barrel product manufactured?

A: This product is manufactured in Zhoushan, China.

Q: What materials are used in the construction of this screw barrel?

A: This screw barrel is constructed using high-quality steel materials for durability and performance.

Q: Can this screw barrel be customized to specific requirements?

A: Yes, customization options are available for this screw barrel to meet specific customer needs.
